代 號(hào)

螺紋 THREAD

管子外徑TUBE O.D.

尺 寸 DIMENSIONS

PART NO.

E

F

D

A

B

S

L

1CG-12-04

M12X1.5

G1/4"X19

6

10.7

10

19

28.5

1CG-14-04

M14X1.5

G1/4"X19

8

13

10

19

31

1CG-14-06

M14X1.5

G3/8"X19

8

13

11.5

22

33

1CG-16-04

M16X1.5

G1/4"X19

10

13.5

10

19

31.5

1CG-16-06

M16X1.5

G3/8"X19

10

13.5

11.5

22

33.5

1CG-16-08

M16X1.5

G1/2"X14

10

13.5

14

27

40.5

1CG-18-06

M18X1.5

G3/8"X19

12

13.5

11.5

22

33.5

1CG-18-08

M18X1.5

G1/2"X14

12

13.5

14

27

38.5

1CG-20-08

M20X1.5

G1/2"X14

14

13.5

14

27

40.5

1CG-22-06

M22X1.5

G3/8"X19

15

13.5

11.5

24

33.5

1CG-22-08

M22X1.5

G1/2"X14

15

13.5

14

27

38.5

1CG-24-08

M24X1.5

G1/2"X14

18

13.5

14

27

40.5

1CG-26-08

M26X1.5

G1/2"X14

18

14

14

27

39

1CG-30-12

M30X2

G3/4"X14

22

18

15.5

32

46.5

1CG-36-16

M36X2

G1"X11

28

18

18

41

50.5

1CG-45-20

M45X2

G1.1/4"X11

35

19

20

50

56

1CG-52-24

M52X2

G1.1/2"X11

42

19

21.5

55

58
